BM-1800
BM-1800 Automatic Block Molding Machine
The BM-1800 is our largest automatic block molding machine, producing blocks up to 1,800 × 1,200 × 600 mm. With the fastest cycle time of 3-5 minutes and SCADA integration, it is the ultimate solution for high-volume continuous production. Energy recovery system reduces operating costs for 24/7 operations.
| Block Size (L×W×H) | 1,800 × 1,200 × 600 mm |
| Cycle Time | 3-5 min |
| Steam Pressure | 0.08-0.12 MPa |
| Steam Consumption | 70-80 kg/cycle |
| Installed Power | 45 kW |
| Density Range | 8-30 kg/m³ |
| Vacuum System | High-capacity water ring pump |
| Machine Weight | 18,000 kg |
| Certifications | CEISO 9001ISO 14001 |
Key Features
- Fully automatic PLC-controlled molding cycle
- Heavy-duty hydraulic mold clamping system
- High-capacity vacuum cooling system
- Automatic material filling with multi-point air-assist
- Adjustable block density from 8-30 kg/m³
- Auto-ejection and block pusher system
- SCADA integration for production line management
- Energy recovery system for reduced operating costs
Applications
Large-scale EPS insulation board productionGeofoam blocks for civil engineeringContinuous 24/7 high-volume production
CE & ISO 9001 Certified 5-Year Warranty 24h Response
