PE-900
PE-900 Batch Pre-Expander
An EPS batch pre-expander is a machine that uses steam to expand raw polystyrene beads to a target density for foam manufacturing. The PE-900 features a 900mm barrel diameter, 300-400 kg/h capacity, and consumes only 50-60 kg of steam per batch with PLC automatic control. It is designed for small to medium EPS factories producing insulation boards, packaging materials, and lightweight construction components.
| Barrel Diameter | 900 mm |
| Capacity | 300-400 kg/h |
| Steam Pressure | 0.15-0.20 MPa |
| Steam Consumption | 50-60 kg/batch |
| Installed Power | 15 kW |
| Expansion Ratio | 40-80 times |
| Machine Weight | 3,000 kg |
| Dimensions (L×W×H) | 2,200 × 1,800 × 3,500 mm |
| Certifications | CEISO 9001 |
Key Features
- PLC automatic control with touch screen interface
- Precision weighing system for consistent density
- Stainless steel barrel for long service life
- Automatic material feeding and discharging
- Energy-saving steam distribution system
- Adjustable expansion ratio for different densities
Applications
EPS packaging material productionLightweight construction insulation boardsSmall to medium scale EPS factories
CE & ISO 9001 Certified 5-Year Warranty 24h Response
