AW-200
AW-200 EPS Wrapping Machine
The AW-200 is an automatic turntable stretch wrapping machine that secures EPS product pallets with stretch film for safe transport and warehouse storage. It wraps 20-35 packs per minute with pre-stretch film technology, PLC-controlled wrapping programs, and a 1,650mm turntable at only 3 kW power. Suitable for EPS and EPP product manufacturers, distribution warehouses, and any production line requiring end-of-line pallet wrapping automation.
| Wrapping Speed | 20-35 packs/min |
| Film Type | Stretch film / PE film |
| Max Product Size | 800 × 600 × 400 mm |
| Installed Power | 3 kW |
| Turntable Diameter | 1,650 mm |
| Machine Weight | 800 kg |
| Dimensions (L×W×H) | 2,200 × 2,200 × 2,500 mm |
| Certifications | CEISO 9001 |
Key Features
- Automatic turntable wrapping system
- Adjustable wrapping layers and tension
- Top and bottom clamping for stability
- Pre-stretch film carriage for film savings
- PLC control with preset wrapping programs
- Photoelectric height detection
Applications
EPS product pallet wrappingFinished goods shipping preparationWarehouse packaging automation
CE & ISO 9001 Certified 5-Year Warranty 24h Response
