SM-1200
SM-1200 Automatic Shape Molding Machine
The SM-1200 is a mid-range automatic EPS/EPP shape molding machine that produces complex foam products with multi-zone steam control for uniform bead fusion. It offers 1,200 x 1,000 mm mold capacity, 25-ton clamping force, and cycle times as fast as 60 seconds with energy-efficient steam distribution. Suitable for manufacturers of cooler boxes, automotive packaging components, helmet liners, and insulated food containers.
| Mold Size (L×W) | 1,200 × 1,000 mm |
| Cycle Time | 60-150 seconds |
| Steam Pressure | 0.08-0.12 MPa |
| Clamping Force | 25 tons |
| Installed Power | 25 kW |
| Ejection System | Hydraulic + pneumatic |
| Machine Weight | 8,500 kg |
| Dimensions (L×W×H) | 3,800 × 2,400 × 3,000 mm |
| Certifications | CEISO 9001 |
Key Features
- PLC automatic control with large touch screen
- High-force hydraulic mold clamping
- Multi-zone steam control for complex shapes
- Automatic ejection and product counter
- Quick mold change system
- Vacuum cooling for reduced cycle times
- Energy-efficient steam distribution
Applications
Cooler boxes and insulated containersAutomotive packaging componentsHelmet liners and protective packaging
CE & ISO 9001 Certified 5-Year Warranty 24h Response
